DIMM 96GB DDR5 6000MHz Kingston Fury Renegade CL32 Kit (2x48)

Kingston FURY KF560C32RSK2-96 is a kit of two 6G x 64-bit

(48GB) DDR5-6000 CL32 SDRAM (Synchronous DRAM) 2Rx8,

memory module, based on sixteen 3G x 8-bit FBGA components per

module. Each module kit supports Intel® Extreme Memory

Profiles (Intel® XMP) 3.0. Total kit capacity is 96GB. Each

module has been tested to run at DDR5-6000 at a low latency timing

of 32-38-38 at 1.35V. The SPDs are programmed to JEDEC

standard latency DDR5-4800 timing of 40-39-39 at 1.1V.

Each 288-pin DIMM uses gold contact fingers. The JEDEC

standard electrical and mechanical specifications are as

follows:

FACTORY TIMING PARAMETERS

• Default (JEDEC): DDR5-4800 CL40-39-39 @1.1V

• XMP Profile #1: DDR5-6000 CL32-38-38 @1.35V

• XMP Profile #2: DDR5-5600 CL40-40-40 @1.25V

• XMP Profile #3: DDR5-4800 CL38-38-38 @1.1V

Features

• Power Supply: VDD = 1.1V Typical

• VDDQ = 1.1V Typical

• VPP = 1.8V Typical

• VDDSPD = 1.8V to 2.0V

• On-Die ECC

• Height 1.54” (39.2mm), w/heatsink

Specification

CL(IDD): 40 cycles

Row Cycle Time (tRCmin): 48ns(min.)

Refresh to Active/Refresh/Command Time (tRFCmin): 295ns(min.)

Row Active Time (tRASmin): 32ns(min.)

UL Rating: 94 V - 0

Operating Temperature: - 0°C to +85°C

Storage Temperature: - -55°C to +100°C
