MS-B550M GAMING WIFI

• AMD Ryzen Ready: Supports Ryzen 1000–5000 Series processors for top-tier performance.

• Dual M.2 & SATA: Fast PCIe X4 M.2 slots and SATA ports for quick storage.•

• Fast Networking: Realtek Gigabit LAN and Wi-Fi 5 (802.11ac) for smooth online gaming.

• RGB Customization: Dual 5V ARGB and 12V RGB headers for personalized lighting.

• USB Ports: Multiple USB 5Gbps and USB 2.0 ports for all your peripherals.

• ESD Protection: Built-in protection prevents static damage for long-term reliability.

• Model MS-B550M Gaming WIFI

• CPU Support – Supports AMD AM4 Socket – Compatible with AMD Ryzen 1000–5000 Series Processors

• Motherboard Form Factor – 22.5 × 20 cm (Micro-ATX)

• Memory Support – 2 × DDR4 DIMM Slots, 2133–3200MHz – Supports A-XMP Profiles

• Power Design – 4+2 Phase Power with Octopus MOS (2 High + 2 Low) Display Outputs – DP + HDMI™

• Networking – 1 × Realtek RTL8111H/M Gigabit Ethernet Port – Built-in Realtek RTL8821CE Wi-Fi Module – Supports IEEE 802.11 a/b/g/n/ac, Bluetooth 4.2

• Storage – 2 × PCIe X4 M.2 Slots (NVMe SSD Support) – 2 × SATA 6Gb/s Ports

• USB Ports Rear USB: – 2 × USB 5Gbps Ports – 4 × USB 2.0 Ports

• Front USB Headers: – 2 × USB 2.0 Headers (4 Ports Total) – 1 × USB 5Gbps Header (2 Ports)

• PCIe Slots – 1 × PCIe X16 (PCIe 4.0, CPU Dependent) – 1 × PCIe X4 (Open-ended)

• ARGB & RGB Headers – 2 × 3-Pin 5V ARGB Headers – 1 × 4-Pin 12V RGB Header

• Other Headers – 1 × Front Panel Audio Header – 1 × 10+1 Pin Front Panel System Header
