Опис
• Intel AX101 WIFI6 Wireless Card
• Max Power Enhanced Power Supply
• High-Speed DDR4 Memory
• ARGB Support
• CHIPSET INTEL B760 High-speed chipset CPU Support for LGA1700 slots The 12th/13th/4th Gen processors TDP: 150W(8+1+1)
• MEMORY 2x DIMM DDR4 memory slots Maximum support in total is 64GB Support to 3200 MHz/OC + memory frequency
• EXPANSION SLOT 1x PCIE X16 4.0 slot 1x PCIE X1 slot Support for AMD and NVIDIA and INTEL graphics cards Support for PCIE resizable bar technology
• STORAGE 2x M.2 4.0 slots (only support 2242 / 2280 PCIE X4 / X2 channel SSD supported only) 3x SATA 3.0 ports USB *On-board rear port: 4x USB 3.2 GEN 1 ports, On-board pins:1X set(2)USB2.0 pins,1X set(2) USB3.2 GEN 1 pins
• NETWORK Integrated REALTEK 8111 chip (10 / 100 / 1000Mbit) 1x onboard R]45 port Support network wakeup Support PXE no disk, UEFI no disk guide
• AUDIO Integrated REALTEK ALC 897 sound chip
• INSIDE BOARD SOCKET 1x 24-PIN motherboard ATX power supply 1x 8-PIN motherboard ATX 12V power supply port, 12V input, 2x sets of system fan pins and 1x group of CPU fan pins、 1x group of PUMP fan pinslx group chassis front control panel pin (F PANEL)
• OPERATING SYSTEM Support for Windows 10 64bit, Windows 11 64bit
• Support for Ubuntu 64bit
• FORM FACTOR Micro ATX 230mm x 205mm
