Опис
• Model MS-Challenger Z890M Form Factor M-ATX (245 × 225 mm)
• CPU Socket Intel® LGA1851, compatible with Intel® Core™ Ultra processors Chipset Intel® Z890
• Memory 2 × DIMM DDR5 slots, supporting dual-channel up to 128GB XMP frequency support up to 7200MHz (OC)
• Display Outputs 1 × HDMI™ 2.0 (4K@60Hz) 1 × DisplayPort 1.2 (4K@60Hz) Expansion Slots 1 × PCIe x16 (supports PCIe 5.0 x16 mode) 1 × PCIe x1 (supports PCIe 4.0 x1 mode) 1 × PCIe x4 (supports PCIe 4.0 x4 mode)
• Audio Integrated Realtek ALC897 audio codec
• Networking Realtek RTL8125BG/D 2.5G Ethernet Intel® AX101 Wi-Fi 6 and Bluetooth 5.2
• Storage 1 × M.2 slot (PCIe 5.0 x4/x2 mode, supports 2242/2280) 1 × M.2 slot (PCIe 4.0 x4/x2 mode, supports 2242/2280) 3 × SATA 6Gb/s ports
• USB Ports Onboard: 1 × USB 3.2 Gen 1 (5G) header, supports 2 additional USB 3.2 Gen 1 ports 1 × USB 2.0 9-pin header, supports 2 additional USB 2.0 ports 1 × USB 3.2 Gen 2 Type-C (10G) front port
• Rear Panel: 4 × USB 3.2 Gen 1 Type-A (5G) ports 2 × USB 2.0 Type-A ports
• Additional Specifications 1 × 24 Pin ATX Power Connector 1 × 8+4 Pin +12V Power Connector 2 × 3 Pin ARGB Headers 1 × 4 Pin NRGB Header 1 × Front COM Port Header
• CLR CMOS Button 1 × 4 Pin CPU_FAN Header 1 × 4 Pin PUMP Header for Water Cooling 2 × 4 Pin SYS_FAN Headers for Case Fans
